BASSBOSS ZV28 MK3 Dual 18" Powered Subwoofer

Name: BASSBOSS ZV28 MK3 Dual 18" Powered Subwoofer
Brand: BASSBOSS
SKU: zv28-mk3-13944

Roll over image to zoom in or

Ships Freight. agiprodj will contact you after ordering to finalize shipping.

Wishlist

Dealer

EZ Returns

Match

Overview

The ZV28-MK3 Subwoofer opens the doors to new experiences… Does your music contain deep bass that demands to be heard? Would you like to introduce audiences to new experiences of the deepest frequencies? Experiences they can’t have anywhere else? This is the sub. With these, you have an incredible opportunity to impress when the music goes deep… You’ll love to see those jaws drop when the bass drops! Those jaws will drop because you’ve brought them something they have never experienced before… and they’ll want more! The ZV28-MK3 Sub will bring your audience up close and personal with the boundaries of audible sound. You will reveal notes unfathomable with other subwoofers, delivered unmistakably large and full.

Specifications:

Loudspeaker Description
- Double 18" Self-Powered Vented Direct-Radiating Extended-depth Subwoofer
- Frequency Response (±3 dB)
- 23 – 90Hz +-3 dB
Maximum Sustained Output
- 134 dB SPL 1m half-space
Max SPL (Peak)*
- 137 dB SPL 1m half-space
Nominal Dispersion (H° x V°)
- 360 x 360 - Cardioid mode available with multiple cabinets
Amplification
- 5000 Watts Class D (2 x 2500W)
Processing
- Integrated comprehensive DSP. 96kHz sampling rate with 8 pushbutton presets. All presets include high pass filters, low pass filters, phase alignment, equalization and multi-stage limiting. Storage apacity for up to 100 presets
Electrical Connector Amp
- Neutrik powerCON True 1 TOP IP65 rated waterproof connectors
- Electrical Connector Mains
- Standard US 3-pin grounding 120V electrical plug: NEMA 5-15 (Edison)
Voltage Operating Range
- 100-240V AC, 50-60Hz (Auto-sensing, auto switching universal supply)
- Current Draw 120V
- 9 Amps (Nominal)
- Current Draw 240V
- 4.5 Amps (Nominal)
Signal Input Connector
- XLR-F
Signal Output Connector
- XLR-M (direct pass-through only)
Enclosure Type
- Direct radiating vented enclosure, optimally tuned for extended low frequency response with linear output and high power handling
Transducer Low Frequency
- 2 x 18” (457mm) neodymium motor woofers with 4.5 in. (115mm) CCAW voice coils
Cabinet Construction
- CNC machined 18mm Birch plywood with extensive bracing and dado joinery. 8 steel bar handles. 2 x 35mm steel pole sockets. 12 rubber feet. 4 interlocking foot pockets. 16 X M10 threaded flypoints
Exterior Finish
- High-pressure, bonded polyurea coating. Rugged, waterproof. Textured black
Grille
- Perforated, powder-coated steel
Dimensions (HxWxD)
- 22.5 in. x 42 in. x 42 in. (Height of feet 7/8")
Net Weight
- 235 lbs. (106.5 kg)
Shipping Weight
- 265 lbs. (120.2 kg)
