The ultimate portable powerhouse on a pole, this is the Mobile Pro's choice. You are a mobile DJ or you have a production company. Your reputation is valuable. Your time is valuable. You want a speaker that's flawless for every gig you do. If you need to cover the largest number of people with the smallest number of boxes, you’re looking at the right loudspeaker. Because almost every gig you do is in a similar sort of space. Because at almost every gig you do, your speakers are on stands, poles, tripods, or truss totems. Because the DV12 is the only speaker in the world that's been designed specifically and exclusively for exactly what you do. Every feature of the DV12 serves to deliver the ideal performance in its intended role: On a pole. Wide horizontal for wide rooms. Tight vertical for intelligibility at distance. Plenty of power so you can rock the party and plug-and-play processing for worry-free operation at any level. A very powerful amplifier feeds the bulk of its power into a beast of a 4" voice coil 12" woofer The rest goes to a 3" voice coil compression driver. The signals are controlled by a high-end DSP to ensure everything comes out loud, clear, smooth, and safe. The cabinet and horn control the coverage. It works. You play.
Specifications:
-
Loudspeaker Description
-
2-Way Active Single 12" Self Powered, Vented, Direct-radiating Full-range
-
Frequency Response (±3 dB)
-
45 – 19,000Hz +-3 dB
-
Maximum Sustained Output
-
128 dB SPL 1m half-space
-
Max SPL (Peak)*
-
134 dB SPL 1m half-space
-
Nominal Dispersion (H° x V°)
-
120 x 20
-
Amplification
-
Processing
-
Integrated comprehensive DSP. 96kHz sampling rate with 8 pushbutton presets. All presets include high pass filters, low pass filters, phase alignment, equalization and multi-stage limiting. Storage apacity for up to 100 presets
-
Electrical Connector Amp
-
Neutrik powerCON True 1 TOP - IP65 rated waterproof connectors
-
Electrical Connector Mains
-
Standard US 3-pin grounding 120V electrical plug: NEMA 5-15 (Edison)
-
Voltage Operating Range
-
100-240V AC, 50-60Hz (Auto-sensing, auto switching universal supply)
-
Current Draw 120V
-
Current Draw 240V
-
Signal Input Connector
-
Signal Output Connector
-
XLR-M (direct pass-through only)
-
Enclosure Type
-
Self-powered, bi-amplified, 2-way full-range. Direct radiating vented LF section, wave-guide-loaded HF section
-
Transducer Low Frequency
-
1 x 12” diameter (300mm) neodymium motor woofer with 4” (100mm) voice coil
-
Transducer High Frequency
-
1 x 3 in. (76mm) diameter diaphragm compression driver with 1.4" (35mm) exit mounted to isophasic wave guide
-
Cabinet Construction
-
CNC machined 15mm Birch plywood with internal bracing and dado joinery. 8 M10 fly points. 1 x 35mm steel pole socket
-
Exterior Finish
-
High-pressure, bonded polyurea coating. Rugged, waterproof. Textured black
-
Grille
-
Perforated, powder-coated steel
You've moved enough gear to know the value of concentrated power. You're tired of performing pseudo-subs because they don't save you any space, time, or money. You're ready for a big sound from a small box. Why not put all the features and power of a big subwoofer into a small cabinet? What if you could get all the sound you need from a small cabinet? Put all the big-box power and technology into a little box and it will deliver on par with those bigger boxes. Why carry more? A solid, braced, Birch cabinet. A 4.5" voice coil Neodymium motor woofer. A 2500-watt amplifier. A premium-grade DSP with proprietary processing and easy plug-and-play presets. The BB15 is very hard to beat!
Specifications:
-
Loudspeaker Description
-
Single 15" Self-Powered Vented Direct-Radiating Subwoofer
-
Frequency Response (±3 dB)
-
40-115Hz +-3 dB
-
Maximum Sustained Output
-
127 dB SPL 1m half-space
-
Max SPL (Peak)*
-
130 dB SPL 1m half-space
-
Nominal Dispersion (H° x V°)
-
360 x 360 – Cardioid Mode Available with Multiple Boxes
-
Amplification
-
Processing
-
Integrated comprehensive DSP. 96kHz sampling rate with 8 pushbutton presets. All presets include high pass filters, low pass filters, phase alignment, equalization and multi-stage limiting. Storage apacity for up to 100 presets
-
Electrical Connector Amp
-
Neutrik powerCON True 1 TOP IP65 rated waterproof connectors
-
Electrical Connector Mains
-
Standard US 3-pin grounding 120V electrical plug: NEMA 5-15 (Edison)
-
Voltage Operating Range
-
100-240V AC, 50-60Hz (Auto-sensing, auto switching universal supply)
-
Current Draw 120V
-
Current Draw 240V
-
Signal Input Connector
-
Signal Output Connector
-
XLR-M (direct pass-through only)
-
Enclosure Type
-
CNC machined 15mm multi-ply Birch laminate with extensive bracing and dado joinery.
-
Transducer Low Frequency
-
1 x 15 in. diameter (380mm) Neodymium motor woofer with 4.5 in. (115mm) voice coil
-
Cabinet Construction
-
CNC machined 15mm Birch plywood with extensive bracing and dado joinery. 2 integrated handles. 1 x 35mm steel pole socket. 4 rubber feet. 16 T-nuts and bolts for mounting optional casters.
-
Exterior Finish
-
High-pressure, bonded polyurea coating. Rugged, waterproof. Textured black
-
Grille
-
Perforated, powder-coated steel
-
Dimensions (HxWxD)
-
20.5 in (521mm) x 17 in (430mm) x 24 in (610mm) (21.25 in. high with feet)
-
Net Weight
-
Shipping Weight
